Surge Arresters
DL-Cat. 6
DL-Cat. 6-60 V
Surge arrester for Ethernet Cat. 6 connectors RJ45
Fine surge protection designed to protect one port of Ethernet Cat. 6. It is installed at the boundary of LPZ 2 and LPZ 3 zones, directly before the equipment.
Including:
universal plastic adapter for DIN rail assembling,
adapter GND 2.
Technical data | DL-Cat. 6 | DL-Cat. 6-60 V |
Location SPD | ST 3 | ST 3 |
Maximum operating voltage Uc | 8,5 V DC / 6 V AC | 8,5 V DC / 6 V AC |
Nominal current IL | 500 MA | 500 MA |
C2 total nominal discharge current (8/20 s) line - PE In | 1,6 kA | 1,6 kA |
C1 nominal discharge current line - line In | 200 A | 200 A |
C2 voltage protection level line - line at In UP | 40 V | 40 V |
C2 voltage protection level line - PE at In Up | 350 V | 350 V |
C3 voltage protection level line - line at 1 kV/s Up | 65 V | 65 V |
Insertion attenuation at 250 MHz | < 2,0 dB | < 2,0 dB |
Response time line - line ta | 1 ns | 1 ns |
Response time line - PE ta | 100 ns | 100 ns |
Degree of protection | IP 20 | IP 20 |
Range of operating temperatures | 40 C + 60 C | 40 C + 60 C |
Connection input output | RJ 45/RJ 45 | RJ 45/RJ 45 |
Mounting on | surface on the desk/DIN rail | surface on the desk/DIN rail |
Meets the requirements of standard | EN 61643-21 | EN 61643-21 |
Ordering number | 8595090536031 | 8595090536031 |
![]() |
